Pneumatic Actuated 1-PC Ball Vavle Flange end
Features
．Investment casting
．Locking devicehandle
．Anti-staticdevice
．Blow-out proof stem
．Automation accessories
．ISO5211 Direct mounting pad
．Live-loading design
Product application industry
The product is suitable for industries such as petroleum, chemical, natural gas, biochemical, pharmaceutical, environmental protection, and new energy.
Technical Specification
DN:Full port，DN15～DN150
W.P:PN16/40 CLASS150
W.T:-20℃～180℃
Body Materia:WCB/CF8/CF8M
Actuator:Pneumatic，Electric motor
lnspection &testing：JB/T 9092 API598
Connection：Wafer type
Connection:Flanged end
